ENGINE

Type

4-stroke, horizontal 6-cylinder, SOHC, 24-valve, liquid-cooled

Displacement

1,833 cc

Valves per cylinder

4

Bore x Stroke

73 mm x 73 mm

Compression ratio

10.5:1

Maximum power

93 kW / 5,500 rpm

Maximum torque

170 Nm / 4,500 rpm

Oil capacity

4.4 liters (MT) / 5.6 liters (DCT)

Noise level (dB)

Wide throttle 76 / City 69

CO2 emissions

127 g/km

FUEL SYSTEM

Carburetor

PGM-FI electronic fuel injection

Throttle bore

50 mm

Air filter

Viscose, cartridge type Paper

Fuel Tank Capacity

21.1 liters

Fuel Consumption

5.5 liters/100 km

ELECTRICAL SYSTEM

Starting

Integrated Starter/Generator System

Battery Capacity

12V/20AH

ACG Alternator Power

12V/120A

DRIVETRAIN

Clutch Type

(DCT) Hydraulic, wet, multi-disc with oil pressure

Transmission Type

DCT: 7-speed forward and reverse

Primary Reduction

1.795 (79/44)

Gear Ratios

(DCT) 1st: 2.167 2nd: 1.696 3rd: 1.304 4th: 1.038 5th: 0.821 6th: 0.667 7th: 0.522 Rev: 1.190

Final Reduction

Engine Side: 0.972

Rear Wheel Side: 2.615

Final Drive

Cardan Shaft

FRAME

Type

Cast aluminum twin-spar

CHASSIS

Dimensions (L x W x H)

L: 2,615 mm

W: DCT 905 mm / MT 925 mm

H: 1,430 mm

Wheelbase

1,695 mm

Rake Angle

30.5°

Cast

109 mm

Turning Radius

3.4 m

Seat Height

745 mm

Ground Clearance

130 mm

Curb Weight

DCT with Airbag 390 kg

SUSPENSION

Front, type

Double wishbone

Rear, type

Pro Link

WHEELS

Front

130/70R 18

Rear

200/55R 16

Front tire size

18 x MT3.5

Rear tire size

16 x MT6.0

BRAKES

System, type

Electronically controlled combined ABS system

Front, type

Dual 320 mm x 4.5 mm hydraulic discs with 6-piston calipers, floating discs, and sintered metal pads

Rear, type

316 mm x 11 mm vented discs with 3-piston calipers and sintered metal pads
