| Frame |
Canyon Speedmax CFR Disc, Canyon Factory Racing triathlon carbon frame, featuring ultra-rare Toray M40X carbon fibres. Shaped by extensive computational fluid dynamics analysis with our aero partners Swiss Side, validated in the wind tunnel. Fully internal routing, integrated hydration system, hidden toolbox, easily accessible bento box, 12×142 mm through axle, flat-mount disc standard., Axle dimension: 12×142 mm, Tyre clearance: 30 mm, Material: Carbon (CFR), Weight: 1,600 g BB Standard: BB86/BB92, 86mm, Press Fit Tire Clearance: 30c Colors: Sparkle Stealth; Champagne Supernova; Chromatic Marvel |
|---|---|
| Fork |
Canyon FK0080, Radical deep profile design, covered brake calipers for enhanced aerodynamics, internal cable routing, 12×100 mm through axle, flat-mount disc standard. CT scanner tested and approved., Axle dimension: 12×100 mm, Fork steer tube diameter: 1 1/8″, Tyre clearance: 30 mm, Material: Carbon (CF), Weight: 660 g |
| Bottom Bracket |
Shimano Pressfit BB92, Bottom bracket standard: PF 86,5, Weight: 55 g |
| Handlebar |
Canyon GP0226 Aerobar, Mono aero bar developed with aero experts Swiss Side to deliver optimal aero performance. |
| Saddle |
Fizik Transiro, Gender: Unisex, Weight: 187 g |
| Seatpost |
Canyon SP0049 Aero Seatpost, Speedmax triathlon seatpost, specifically designed for pure aero performance, non-UCI-compliant profile., Material: Carbon (CF), Weight: 154 g Type: Rigid |
| Pedals |
None included |
| Rear Derailleur |
Shimano Dura-Ace Di2 RD-R9250, 12-speed, Cage length: long, Weight: 217 g |
|---|---|
| Front Derailleur |
Shimano Dura-Ace Di2 FD-R9250, Weight: 96 g |
| Crank |
Shimano Dura-Ace R9200, Number of chainrings: 2 |
| Shifters |
Shimano Dura-Ace Di2 R9160 Remote TT, Weight: 19 g |
| Cassette |
Shimano Dura-Ace CS-R9200, Number of sprockets: 12, Range: 11-30 |
| Chain |
Shimano XTR |
| Brakes |
Shimano Flat Mount Adapter +20mm Type: Shimano Hydraulic Disc |
| Brake Levers |
Shimano Dura-Ace Di2 ST-R9180, Number of pistons: 2, Weight: 263 g | Shimano Dura-Ace Di2 ST-R9180, Number of pistons: 2, Weight: 264 g |
| Rims |
DT Swiss ARC 1100 Dicut, Axle dimension: 12×100 mm, Rotor mount: Center Lock, Rim height: 80 mm, Inner width: 20 mm, Rim material: Carbon, Weight: 828 g | DT Swiss ARC 1100 Dicut, Axle dimension: 12×142 mm, Rotor mount: Center Lock, Rim height: 80 mm, Rim material: Carbon, Weight: 942 g |
|---|---|
| Tires |
Continental Grand Prix 5000 S TR, 28mm, Width: 28 mm, Weight: 294 g | Continental Aero 111, Width: 26 mm, Weight: 246 g |
| Disc Rotors |
Shimano Dura-Ace RT-CL900, Size: 160 mm, Weight: 113 g |
