| *Frame | Size: 56, 47, 58, 60, 50, 62, 52, 54
800 Series OCLV Carbon, KVF (Kammtail Virtual Foil) tube shape, adjustable top tube IsoSpeed, invisible cable routing, 3S aero chain keeper, T47 BB, DuoTrap S compatible, flat mount disc, 142x12mm thru axle
|
|---|---|
| *Fork | Size: 56, 47, 58, 60, 50, 62, 52, 54
Madone KVF full carbon, tapered carbon steerer, invisible cable routing, flat mount disc, carbon dropouts, 12x100mm thru axle
|
Weight
| Weight | 56 – 8.00 kg / 17.64 lbs |
|---|---|
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 275 pounds (125 kg). |
E-system
| *Battery | Size: 56, 47, 58, 60, 50, 62, 52, 54Shimano BT-DN300 |
|---|---|
| *Charger | Size: 56, 47, 58, 60, 50, 62, 52, 54
Charging cable included
|
Drivetrain
| *Shifter | Size: 56, 47, 58, 60, 50, 62, 52, 54
Shimano Ultegra R8170 Di2, 12 speed
|
|---|---|
| *Front Derailleur | Size: 56, 47, 58, 60, 50, 62, 52, 54Shimano Ultegra R8150 Di2, braze-on, down swing |
| *Rear Derailleur | Size: 56, 47, 58, 60, 50, 62, 52, 54
Shimano Ultegra R8150 Di2, 34T max cog
|
| *Crank | Size: 47
Shimano Ultegra R8100, 52/36, 165mm length
|
| Size: 50, 52Shimano Ultegra R8100, 52/36, 170mm length | |
| Size: 56, 58, 54Shimano Ultegra R8100, 52/36, 172.5mm length | |
| Size: 60, 62Shimano Ultegra R8100, 52/36, 175mm length | |
| *Bottom Bracket | Size: 56, 47, 58, 60, 50, 62, 52, 54Praxis, T47 threaded, internal bearing |
| *Cassette | Size: 56, 47, 58, 60, 50, 62, 52, 54Shimano Ultegra R8100, 11-30, 12 speed |
| *Chain | Size: 56, 47, 58, 60, 50, 62, 52, 54
Shimano Ultegra/XT M8100, 12 speed
|
Wheels
| *Front Wheel | Size: 56, 47, 58, 60, 50, 62, 52, 54Bontrager Aeolus Pro 51, OCLV Carbon, Tubeless Ready, 100x12mm thru axle |
|---|---|
| *Rear Wheel | Size: 56, 47, 58, 60, 50, 62, 52, 54
Bontrager Aeolus Pro 51, OCLV Carbon, Tubeless Ready, Shimano 11/12-speed freehub, 142x12mm thru axle
|
| *Front Skewer | Size: 56, 47, 58, 60, 50, 62, 52, 54Bontrager Switch thru axle |
| *Rear Skewer | Size: 56, 47, 58, 60, 50, 62, 52, 54Bontrager Switch thru axle, removable lever |
| *Tire | Size: 56, 47, 58, 60, 50, 62, 52, 54Bontrager R3 Hard-Case Lite, aramid bead, 120 tpi, 700x25mm |
| Max tire size | 28mm |
Components
